CHV-04 Model

To receive the best support and obtain a free quotation from Chí Hướng Mechanical Company (CHIHO), please provide your contact phone number.

Machine specifications:
CHV-04 Model

Machine weight: 630 kg

Height: 1500 mm

Width: 700 mm

Length: 2300 mm

Product type: Can bend more than 30 types of belts

Capacity: 2.5-3 tons of iron / 1 day.

Machine power: Electric motor 3 phase 3hp USTRALIA/ 1 phase YUNSHUN Taiwan

Machine speed: 18-20 belts/minute. Square belt bending speed 17-20 belts/minute (150x150mm)

Machine motor: YUKEN hydraulic pump from Japan, made in Taiwan, 30 liters/minute, creating pressure of 70kg/cm2

Electrical system: 380v/220v(50-60 Hz)

Electrical cabinet: Electrical cabinet system controlled by PLC software circuit board (CHIHO)

Screen: 9 INCH TOUCH display screen

Specifications of automatic iron belt bending machine 6-8-10mm Model CHV-03

Dimensions (LxWxH): 2300 x 700 x 1500 (mm)
Weight: 630 kg
Speed: 18-20 belts/minute
Bendable: More than 30 belt styles
Yield: 2.5-3 tons of iron/day.

How much does an iron belt breaker cost and its applications | Find out the price list of belt bending machines

SKU: CHV03 Categories: AD, automatic iron bending machine, CHIHO products, máy bẻ đai sắt tự động phi 6 8 10 Tags: máy bẻ đai sắt, máy bẻ đai sắt phi 6 8 10 12, máy bẻ đai sắt xây dựng

0947 000 155

kết nối Facebook

Description
Reviews (10)

Automatic iron belt bending machine Model CHV-03 specializes in running 6-8-10mm iron belts with classy designs to help speed up construction progress. CHV-03 is a super durable, super fast machine, runs on 10mm belts (iron and 10mm rolled iron) with dimensions of 1000x500mm, extremely sturdy frame, fast bending and cutting, and many other superior features.

(Image of automatic iron belt bending machine VIETNAMESE DOLPHIN CHIHO Phi 10mm Model CHV-03)

(Video Running 10mm Flying Iron on 11m7 Tree)

Viet Phi Dolphin 10 CHV-03 is a specialized machine used in super large projects such as bridges and roads, concrete factories, ditches, highways,… especially 6-8- belt breaking. 10mm with the largest belt size super large 1000x500mm. This line of iron belt bending machines is a combination of the most outstanding advantages of our products. With over 30 belt styles and easily customizable sizes on the color touch screen.

Máy bẻ đai sắt CÁ HEO VIỆT -CHV-02 — Iron belt bending machine VIETNAM DOLPHIN 10mm Model CHV-03

TECHNICAL SPECIFICATIONS OF VIETNAMESE DOLPHIN CHIHO AUTOMATIC IRON BELT BREAKING MACHINE 6-8-10mm:

Dimensions: 2300 x 1500 x 700 (mm)

Weight: 630 kg
C45 and SKD11 steel abrasive systems exactly process each part
Hydraulic control system
– 3-phase 3hp electric motor USTRALIA/ 1-phase YUNSHUN Taiwan
– Power source: 380v/220v (50-60 Hz)
– KEIKI TOKYO control valve from Japan
– Japanese YUKEN hydraulic pump made in Taiwan, 30 liters/minute, creating pressure of 70kg/cm2
– Electrical cabinet system controlled by PLC software circuit board (CHIHO)
– 9 INCH TOUCH display screen
– Break construction iron straps 6-10 mm
– Square belt bending speed 17-20 belts/minute (150x150mm)
– Largest belt size: 1000×500 (mm)
– Can bend more than 30 types of belts
– CASTOL AWS hydraulic oil
– Easy to adjust individual stretchers
– 2-blade knife set is especially durable and cuts smoothly
– SUPPORT CHIHO IOT 4.0 APP
